Z2F

產品認證：

●CQC證書號 CQC Certificate number: CQC21002296113

●TUV證書號 TUV Certificate number: R50503055

●UL證書號 UL Certificate number: E502802

典型應用：

● 家用電器：空調、電熱器等 Home appliances: air conditioner, electric heater, etc.

● OA設備：電腦、傳真機等 OA Equipment: computer, fax machine, etc.

● 自動售貨機 Vending Machine

●10A觸點切換能力，有16A可選 10A contact switching capability, 16A optional

●塑封型和防焊劑型 Plastic seal type and flux proof type

●線圈觸點間耐壓4KV Designed to meet 4kv dielectric between coil and contacts

●可提供敏感型和標準型線圈 Sensitive and standard coils available

●環保產品（符合ROHS）Eco-friendly products (ROHS compliant)

●外形尺寸 Overall dimension: 18.2X10.2X14.6mm




	Z2F	-12	D	H	-1	A	S	X
基本型號 Type Z2F
線圈額定電壓 Coil voltage 05=5VDC, 06=6VDC, 09=9VDC, 12=12VDC, 24=24VDC
線圈功耗 Coil Power D=0.36W L=0.2W
觸點負載Contact Load 空白 Blank=5A; H=10A; T=16A
接點極數 Contact Pole 1-1極Pole
觸點結構 Contact of arrangement 1A=1FormA常開型
封裝形式Enclosure 空白Blank=非密封型Vented Plastic Case; S=密封型Sealed Plastic Case
特殊標記 Suffix Blank=Standard, (XXX)=客戶特殊需求 Customer Special Requirement
