● 20A觸點切換容量 20A
switching capability
● 觸點與線圈間介質耐壓5KV
5KV dielectric strength (between coil and contacts)
● 具有單線圈與雙線圈可供選擇
Both 1 coil and 2 coils available
● 低高度僅15.7mm
Low height: 15.7mm
Z15K | -12 | A | XXX | |||
基本型號 Type Z15K | ||||||
線圈額定電壓 Coil voltage 03，05，06，09，12，18，24VDC | ||||||
線圈 Coil Sort Blank=1 coil; 2=2 coils | ||||||
觸點結構 Contact of Arrangement 1A=1Form A; 1C=1Form C；2A=2Form A; 2C=2Form C | ||||||
封裝形式 Category of Protection Blank=非密封型 Flux proof; S=密封型 Wash tight | ||||||
特殊標記 Suffix Blank=Standard, (XXX)=客戶特殊需求 Customer Special Requirement | ||||||
